Lens
EF 1:1.8 50mm STM
Zoom range (mm)
80
Lens factor
1
Minimum aperture range (f-stops)
1.8
Minimum shutter speed (secs)
1/4000
Maximum shutter speed (secs)
30
Lens diameter (mm)
70
Lens length (mm)
47
Lens weight (g)
160
Lens filter thread (mm)
49
Lens mount
Canon EF
Sensor type
CMOS
Sensor size
22.3 x 14.9
Effective resolution (MP)
17.9
Dimensions (mm, WxHxD)
130 x 101 x 83
Weight (g)
522
Tripod socket
Metal (centred)
Start-up time (sec)
0.5
Shutter delay 1m (sec)
0.22
Shutter delay 8.5m (sec)
0.42
ISO rating
100 – 6400
Exposure correction (lower)
-5
Exposure correction (higher)
5
Continuous shooting mode
2.9
Frame limit in continuous mode
1000
Number of selectable exposure programs
12
Closest focus wide (m)
0.35
Closest focus tele (m)
0.35
Closest focus macro (m)
Not applicable
Focus points (auto mode)
9
Monitor size (mm)
60 x 45
Monitor ratio
4:3
Monitor swivel (V x H, deg)
Fixed
Viewfinder type
Optical SLR viewfinder (TTL)
Viewfinder diopter
-2.5 x 0.5
Video ratios supported
4:3, 16:9
Video format
MOV (codec MPEG-4 AVC/H.264)
Maximum frame rate – progressive
30
Number of selectable exposure programs – video
2
Audio recording format
Mono
Memory card type
SDHC, SDXC
Internal memory (MB)
None
Number of memory cards – insertable
1
Image ratios supported
3:2, 4:3, 16:9
Flash type
pop-up auto, pop-up manual
Battery type
Li-Ion (1)
CIPA battery cycles
180
Image editing software
EOS Digital Solution Disk Software 31.1A (Win/Mac)
RAW converter software
Digital Photo Professional 4.4.30 (Win/Mac)
Video editing software
EOS Digital Solution Disk Software 31.1A (Win/Mac)
